CNC Gabion Mesh Weaving Machine

Weaves galvanized or PVC-coated wire into 3- and 5-twist hexagonal mesh.

Also known as: hexagonal wire mesh machine · gabion netting machine · triple-twist mesh weaver

Mesh opening: 60 × 80 / 80 × 100 / 100 × 120 mm, or as specified
Wire diameter: 1.0 – 4.0 mm (galvanized, Galfan or PVC-coated)
Max. mesh width: 5600 mm

CNC gabion mesh weaving machine in the workshop with hexagonal mesh on the loom

Overview

The core machine of every gabion line. Servo-driven pitch and wire feed hold the mesh opening steady across the full width, and a stress-relieved frame keeps the gantry square after years of three-shift running. The documented vertical CNC model uses PLC touchscreen control, switches 3-twist, 5-twist, doubled mesh opening and alternating 3- and 5-twist production with one key, and includes length counting, automatic stop and alarm, and centralized automatic lubrication.

Technical data

Mesh opening: 60 × 80 / 80 × 100 / 100 × 120 mm, or as specified
Wire diameter: 1.0 – 4.0 mm (galvanized, Galfan or PVC-coated)
Max. mesh width: 5600 mm
Control system: PLC with HMI, servo-driven feed and pitch
Total motor power: 52 kW
Machine weight: 17 T
Power supply: 380 V / 50 Hz, three phase (or to your local standard)
Machine functions: 3-twist, 5-twist, doubled mesh opening and alternating 3- and 5-twist production
Weaving speed: 70 picks/min (3-twist); 60 picks/min (5-twist)
Motor count: 3
Main beam: High-strength, one-piece beam
Control interface: Touchscreen, buttons and handheld controller
Control voltage: 24 V
Included accessories: One five-roller wire straightening machine
Gearbox / reducer brand: Taizhixing (泰之星)
Gearbox / reducer models: TZX20, TZX36, TZX100; precision planetary reducer
Reduction ratios: 20 / 36 / 100
Output torque: 10,000
Servo motors: Raynen MC2D-T2015KC-E1B2 or MC2D-T2022KC-E1B2
Servo drives: Raynen RA3E-32RT or RA3E-45RT
PLC: JUNCAUTO JH2M-32T8-E-A
Touchscreen / HMI: JUNCAUTO TM100E-4G-V
Bearings (selected): Wafangdian: 6226-2R5, 22320, 22214, 22320CA/W33, and others
Main electrical components: CHINT (正泰)
Gear material: 20CrMnTi
Gear heat treatment: Carburizing

Specifications are configured per order. Send your mesh sizes and we will confirm the exact build.

Get a quotation

Why this machine, and not the cheapest one on the market

PLC touchscreen control

Adjust mesh settings on screen and select 3- or 5-twist mesh.

Servo transmission

Replaces the mechanical swing-arm and gear drive.

Smooth, fast weaving

Multi-layer spring design and electronic cam reduce vibration and noise.

Automatic monitoring

Counts length, stops and alarms, and lubricates centrally.

Common questions

All FAQs

What mesh sizes can the CNC gabion mesh weaving machine produce?

It is built to the range you specify — typically 60 × 80 / 80 × 100 / 100 × 120 mm, or as specified, with wire diameters of 1.0 – 4.0 mm (galvanized, Galfan or PVC-coated).

Can it be built for our power supply and language?

Yes. Electrical panels are configured for your voltage and frequency, and the control interface language is set at build time to match your operators.

What is the lead time and how is it shipped?

Lead time is confirmed in writing with your quotation. Machines are packed for sea freight, loaded with photographic records and shipped with the documentation your broker needs.
